Structure of ribbon blender

The horizontal belt mixer is composed of U-shaped cylinder, transmission parts and belt mixing blades. The belt mixing blades are usually double-layer or three-layer.

The outer screw collects the materials from the side to the center, and the inner screw transports the materials from the center to both sides to form convective mixing.

Working Method of BSR Hrizontal Mixer Powder Mixing Machine

BSR series ribbon mixer is mainly composed of mixing drum, spiral ribbon and driven parts. The spiral ribbon consists of two layers.

Namely, the inner belt makes the material move outwards, the outer belt makes the material move inwards, forming a good material circulation.

The circular motion of the ribbon enables the mixer to achieve good mixing efficiency in a very short time.

If you are looking for dry powder blenders, such as spice powder blenders, protein powder blenders, spice powder blenders, our bsr ribbon blenders are a very good choice.

Model	Max work volume(volume)	Speed(rpm)	Motor(kw)	Overall size(mm)	weight(Kg)
BSR-100	60L	76	2.2	1080(L)758(W)615(H)	330
BSR-300	180L	66	4	1550(L)812(W)1015(H)	780
BSR--500	300L	66	5.5	1975(L)1059(W)1120(H)	955
BSR-1000	600L	41	11	2340(L)1380(W)1455(H)	1400
BSR-2000	1200L	33	18.5	2480(L)1651(W)1805(H)	2500
BSR-3000	1800L	33	22	2945(L)1896(W)1980(H)	3300
BSR-4000	2400L	29	22	3038(L)1946(W)2205(H)	3600
BSR-5000	3000L	29	30	3932(L)2010(W)2035(H)	4620
BSR-6000	3600L	26	37	3938(L)1882(W)2246(H)	5300
BSR-8000	4800L	26	45	3986(L)2160(W)2516(H)	6800
BSR-10000	6000L	19	55	4500(L)2270(W)2667(H)	8900
BSR-12000	7200L	19	55	4500(L)2466(W)2785(H)	9520
BSR-15000	9000L	17	75	5363(L)2470(W)3020(H)	9950
BSR-20000	12000L	17	75	5670(L)2650(W)3497(H)	11140

Ribbon Blender Hrizontal Mixer Powder Mixing Machine
