Working Method:

Its operation principle is that the vegetables and fruits in the water tank will be continuously washed by the high-pressure rolling bubbles driven by the net chain. With the action of the rotary brush, the water in the water tank will be further cleaned by spraying after repeatedly flushing the water. The water in the water tank is filtered by the auxiliary water tank and fed into the water tank through the pipeline pump. If it is necessary to disinfect, one can be added in the water tank Fixed concentration of disinfectant can also be heated by steam.

Features:

1. High pressure air bubble and spraying water can wash off dirt, sands and other residues

2. Equipped with VFD to better adjust the belt speed

3. Equipped with separate filter tank and water recycling system
4. Equipped with spraying section with clean water for twice washing The objects are automatically conveyed to spraying section by the conveyor mesh belt.

Advantages:

1. Mufti-function, wide application, will not hurt products.

2. Mesh belt conveying , speed adjustable. washing machine.

3. With secondary spray system and water recycling system, saving water.

4. Can add ozone and ultrasonic generator. washing machine.

5. The bearings are imported stainless steel bearings to make energy saving.

Technical Data:

Model	BSQP-3500	BSQP-4000	BSQP-5000
Overall dimension (mm)	350014001350	400016001350	500016001350
Power (kw)	4.07	4.87	5.25
Belt width (mm)	600	800	800
Net weight of equipment (kg)	360	500	700
Capacity (kg / h)	about750	about1250	about1750
speed	frequency control

BSQP Vegetable And Fruit Washing Machine Air Bubble Washing Machine
