this is our joint type BS-200 hammer mill,you can see how to change the screen in this milling machine.
This spie grinder can be widely used to grind many kinds of materials,such as chili,pepper,cinnamon,cumin,bandits,nutmeg,gralic,cloves,giinger ...etc,For root ,herb and leaf,its grinding effect is also good.
This machine is composed of crusher part, cyclone separator, dust box, blower, control box, etc.
It uses the relative movement between the fixed plate and the movable hammer to cause the material to be impacted and broken under the action of centrifugal force.
Can be up to 10%-20% of the oil content of spices and oil materials for grinding. After continuous operation, the temperature of the grinding room remains normal, and the color and smell of the material will not change after grinding.
This machine has a good effect on different condiments, such as pepper, pepper powder, black pepper, white pepper, green pepper, cinnamon, cumin, mashed potato, cinnamon, nutmeg, cardamom, red yeast rice, red pepper, garlic, star anise, clove, grass fruit, geraniol, turmeric, ginger, fennel, fennel, angelica and other substances with high oil or fiber content.
The grinding effect of roots, herbs and leaves is also very good.
|Speed of principal axis(rpm)||2950||2500|
|Grinding fineness (mesh)||12-120||12-120||12-120||12-120|
|Main crush motor(KW)||22||37||45||55|
|Overall size (L*W*H)（mm）||5400*1300*2700||6800*1300*2700||7800*1800*3200||8800*2000*3300|
